PASLANMAZ DİKİŞLİ VE DİKİŞSİZ BORU AĞIRLIK CETVELİ |
|
Çekme Borular |
Dış Çap
(mm) |
>= 10,30
< 48,30 |
>= 48,30
< 114,3 |
>= 114,3
< 219,1 |
>= 219,1
< 457,2 |
Tolerans
(mm) |
+ 0,40
- 0,79 |
± 0,79 |
+ 1,59
- 0,79 |
+ 2,38
- 0,79 |
|
Et Kalınlık Toleransı |
-12,5 % |
-12,5 % |
-12,5 % |
-12,5 % |
|
Dikişli Borular |
Dış Çap
(mm) |
>= 17,15
< 48,26 |
>= 60,33
< 114,3 |
>= 114,3
< 219,1 |
>= 273,1
< 406,4 |
Tolerans
(mm) |
+ 0,40
- 0,79 |
± 0,79 |
+ 1,59
- 0,79 |
+ 2,38
- 0,79 |
|
Et Kalınlık Toleransı |
-12,5 % |
-12,5 % |
-12,5 % |
-12,5 % |
|
PASLANMAZ BORU AĞIRLIK CETVELİ |
|
Ölçü |
Kalınlık |
|
mm |
1.0 mm |
1.2 mm |
1.5 mm |
2.0 mm |
2.5 mm |
3.0 mm |
4.0 mm |
5.0 mm |
6.0 mm |
|
|
|
10,00 |
0,225 |
0,264 |
0,319 |
|
|
|
|
|
|
|
12,00 |
0,275 |
0,325 |
0,394 |
0,5 |
|
|
|
|
|
|
14,00 |
0,326 |
0,385 |
0,47 |
0,601 |
|
|
|
|
|
|
15,00 |
0,351 |
0,415 |
0,507 |
0,651 |
|
|
|
|
|
|
16,00 |
0,376 |
0,445 |
0,545 |
0,701 |
|
|
|
|
|
|
17,20 |
0,406 |
0,481 |
0,59 |
0,761 |
0,921 |
|
|
|
|
|
18,00 |
0,426 |
0,505 |
0,62 |
0,801 |
|
|
|
|
|
|
19,00 |
0,452 |
0,536 |
0,659 |
0,854 |
|
|
|
|
|
|
20,00 |
0,476 |
0,565 |
0,695 |
0,901 |
1,906 |
|
|
|
|
|
21,30 |
0,508 |
0,604 |
0,744 |
0,967 |
1,177 |
1,375 |
|
|
|
|
22,00 |
0,526 |
0,625 |
0,77 |
1,002 |
|
|
|
|
|
|
23,00 |
0,551 |
0,655 |
0,808 |
1,051 |
|
|
|
|
|
|
25,00 |
0,601 |
0,715 |
0,883 |
1,152 |
1,409 |
1,653 |
|
|
|
|
25,40 |
|
0,898 |
1,172 |
|
|
|
|
|
|
|
26,90 |
0,649 |
0,772 |
0,954 |
1,247 |
1,527 |
1,795 |
|
|
|
|
28,00 |
0,676 |
0,805 |
0,995 |
1,302 |
1,596 |
1,878 |
|
|
|
|
30,00 |
0,726 |
0,865 |
1,07 |
1,402 |
1,722 |
2,028 |
|
|
|
|
32,00 |
0,776 |
0,925 |
1,146 |
1,502 |
1,847 |
2,178 |
|
|
|
|
33,00 |
|
|
1,184 |
|
|
|
|
|
|
|
33,70 |
0,819 |
0,977 |
1,209 |
1,588 |
1,953 |
2,306 |
2,975 |
|
|
|
35,00 |
0,851 |
1,016 |
1,258 |
1,653 |
2,035 |
2,404 |
|
|
|
|
38,00 |
0,929 |
1,109 |
1,375 |
1,808 |
2,229 |
2,637 |
|
|
|
|
40,00 |
0,977 |
1,166 |
1,446 |
1,903 |
2,348 |
2,779 |
3,606 |
|
|
|
42,00 |
|
1,226 |
|
|
|
|
|
|
|
|
42,40 |
1,037 |
1,238 |
1,536 |
2,023 |
2,498 |
2,96 |
3,847 |
|
|
|
43,00 |
|
1,257 |
1,559 |
|
2,536 |
|
|
|
|
|
45,00 |
1,102 |
1,316 |
1,634 |
2,153 |
2,661 |
3,155 |
|
|
|
|
48,30 |
1,184 |
1,415 |
1,758 |
2,319 |
2,867 |
3,403 |
4,438 |
|
|
|
50,00 |
1,227 |
1,466 |
1,822 |
2,404 |
2,974 |
3,531 |
4,607 |
|
|
|
50,80 |
1,247 |
1,49 |
1,852 |
2,444 |
|
3,591 |
|
|
|
|
51,00 |
1,252 |
1,496 |
1,859 |
2,454 |
3,036 |
3,606 |
|
|
|
|
52,00 |
1,277 |
1,526 |
1,897 |
2,504 |
3,099 |
3,681 |
|
|
|
|
53,00 |
|
|
1,935 |
|
|
|
|
|
|
|
54,00 |
1,327 |
1,587 |
1,972 |
2,604 |
3,224 |
3,831 |
|
|
|
|
55,00 |
|
|
2,01 |
|
|
|
|
|
|
|
57,00 |
|
|
2,085 |
2,754 |
3,412 |
4,057 |
5,309 |
|
|
|
60,30 |
1,485 |
1,776 |
2,209 |
2,92 |
3,618 |
4,304 |
5,64 |
|
|
|
63,00 |
|
|
2,31 |
3,055 |
|
|
|
|
|
|
63,50 |
1,565 |
|
2,329 |
3,08 |
3,819 |
4,545 |
5,96 |
|
|
|
70,00 |
1,728 |
2,067 |
2,573 |
3,405 |
4,226 |
5,033 |
6,611 |
|
|
|
76,00 |
|
|
2,799 |
3,706 |
|
|
|
|
|
|
76,10 |
1,881 |
2,251 |
2,802 |
3,711 |
4,607 |
5,491 |
7,222 |
|
|
|
80,00 |
1,978 |
2,368 |
2,948 |
3,906 |
4,852 |
5,784 |
7,613 |
|
|
|
84,00 |
|
|
|
4,107 |
|
|
|
|
|
|
88,90 |
|
|
3,283 |
4,352 |
5,409 |
6,453 |
8,504 |
|
|
|
101,60 |
|
|
3,76 |
4,988 |
6,204 |
7,407 |
9,776 |
12,094 |
14,363 |
|
104,00 |
|
|
3,85 |
5,108 |
6,354 |
7,587 |
10,016 |
12,395 |
14,724 |
|
108,00 |
|
|
|
|
6,605 |
7,888 |
10,42 |
|
|
|
114,30 |
|
|
4,237 |
5,624 |
6,999 |
8,361 |
11,048 |
13,684 |
16,271 |
|
129,00 |
|
|
4,789 |
6,36 |
7,919 |
9,465 |
12,52 |
15,525 |
18,48 |
|
139,70 |
|
|
5,191 |
6,896 |
8,589 |
10,269 |
13,592 |
16,864 |
20,087 |
|
154,00 |
|
|
5,728 |
7,612 |
9,484 |
11,343 |
15,024 |
18,655 |
22,236 |
|
168,30 |
|
|
6,245 |
8,328 |
10,379 |
12,417 |
16,456 |
20,445 |
24,384 |
|
|
|
